HTGJ-10M-3 Pipe Hydrostatic Pressure and Burst Testing Machine for Plastic Pipe 0-20MPa Touch Screen/PC Control
Introduction:
The machine is designed and manufactured according to GB/T6111 Thermoplastics pipes for the conveyance of fluids ----Resistance to internal pressure----Test method and GB/T15560Standard test method for short-time hydraulic failure and resistance to constant internal pressure of the plastics pipes for the transport of fluids . It is suitable to determine the pressure-resisting broken time or the maximum pressure value of instantaneous blast of thermoplastic pipes and compound pipes (such as PP-R ,PP-B ,PP-A ,PE ,PE-X ,PVC ,PVC-U and PVC-C ) under long-term constant internal pressure and temperature .It is indispensable for manufacturers of plastic pipes and testing institutions .
Feature:
1)This instrument is used for testing a certain range of internal pressure in a long period of time of plastic pipes.
2)The instrument consists of a pressure host, a pressure station, a water tank, a temperature control system and a computer software system.
Main Frame: It consists of pressure micro control parts, automatic filling pressure and electric discharge pressure parts, pressure micro control part adopts the microcomputer MCU control; equipped with high resolution, high speed of ∑ - delta 16-bit adc chip, real-time communication and computer; and it can automatically fill and relief pressure according to the situation of pressure.
Pressure Station: Its main function is to provide pressure to the main frame, the requirement of lower limit pressure of pressure station requirement must be higher than all tested specimen. The plunger pump of the station is made in the United States (large flow, low noise, high pressure, free maintenance).
Water Tank: It consists of electric opening part, self-circulation part, heating part, automatic water filling part and insulation part.
Temperature Control System: Accurately control the temperature of the water tank, temperature display, set temperature individually. It can control the liquid level of tank at a reasonable position, at the same time it can also guarantee the temperature.
Software System: By connecting with RS232 serial interface to the pressure on the host, it can provide the parameters setting, calibration, pressure relief, zero, amplitude modulation, drawing the test, test records and print test reports and other functions.
Application:
The instrument is widely used in the internal pressure test of all kinds of plastic pipes. It is the ideal testing instrument for construction industry, Plastic pipe producers, national testing sectors and the scientific research sectors.
Working Conditions:
Following conditions must be satisfied to conduct a test:
(1) Ambient Temperature: 10℃～40℃;
(2) Ambient Temperature: 30%—80%;
(3) Vibration-free,no corrosive medium environment;
(4) Install and adjust the instrument to level on a solid foundation;
(5) No strong electromagnetic interference and no strong wind resistance;
(6) A indoor exhaust system is needed to prevent the instrument
Main specifications:
1. test pressure and time separately control within 3 lines
2. pressure adding range :0~10.000MPa
3. Max. working pressure of main pressure system 16MPa
4. high pressure piston pump
(1) pressure : 16MPa
(2) volume :8-11.3L/min
(3) rotating speed :920rpm/min
5 .pressure controlling precision :+2% and -1% of upper and lower limit of
test pressure value respectively
6. resolution of pressure value :0.001Mpa
7. transformer :test pressure sampling periods is 0.1 millisecond .
8. timing range :0—9999h
9. timing precision :1S
Structure and theory:
The high pressure liquid generated by high pressure pump is transported to samples in media temperature constant tanks through high pressure hoses to carry out pipe long time hydrostatic pressure tests after being measured by main engine of pressure control system
